PLC FX1N-14MR-001 24MR 40MR 60MR/M

Mitsubishi plc FX1N series product details:

●FX1N series is a very powerful micro PLC, and can add special function modules or expansion boards.

●Communication and data link function options make FX1N very good in important applications such as volume, communication and special function modules and energy control.

●Host points 14/24/40/60, divided into transistor output/relay output, AC power supply/DC power supply, expandable to 128 points.

●8000 step storage capacity, and can be connected to a variety of expansion modules, special function modules, expandable to up to 128I/O points.

●Positioning and pulse output function: Each phase in a PLC unit can output 2 points of 100KHz pulses at the same time.

●PLC is equipped with 7 special positioning instructions, including zero return, relative address expression and special pulse output control.

●Connect the display module or analog quantity through the expansion board to expand the input and output points.

●The expansion board can be used to add analog potentiometers, and the input and output points are increased.

●And the display module FX1N-5DM can be installed, which can monitor and edit timers, counters and data registers.
●Analog input and output can also be realized through FX1N-2AD-BD and FX1N-1DA-BD.
●Network and data communication functions: A variety of communications and data links can be realized by connecting expansion boards or special adapters.
●Through FX2N-16CCL and FX2N-32CCL, it can act as a CC-LINK master or slave.

Mitsubishi PLC FX1N series product models:

FX1N basic unit

FX1N-60MR-001 relay type, 36-point input/24-point output, AC
FX1N-40MR-001 relay type, 24-point input/16-point output, AC
FX1N-24MR-001 relay type, 14-point input/10-point output, AC
FX1N-14MR-001 relay type, 8-point input/6-point output, AC
FX1N-60MR-D relay type, 36-point input/24-point output, DC
FX1N-40MR-D relay type, 24-point input/16-point output, DC
FX1N-24MR-D relay type, 14-point input/10-point output, DC
FX1N-60MT-001 transistor type, 36-point input/24-point output, AC
FX1N-40MT-001 Transistor type, 24 input/16 output, AC
FX1N-24MT-001 Transistor type, 14 input/10 output, AC
FX1N-14MT-001 Transistor type, 8 input/6 output, AC
FX1N-60MT-D Transistor type, 36 input/24 output, DC
FX1N-40MT-D Transistor type, 24 input/16 output, DC
FX1N-24MT-D Transistor type, 14 input/10 output, DC
FX1NC basic unit
FX1NC-16MT Transistor type, 8 input/8 output, DC
FX1NC-32MT Transistor type, 16 input/16 output, DC
FX1N special function modules:
FX1N-1DA-BD 1 channel analog output
FX1N-2AD-BD 2 channel analog input
FX1N-2EYT-BD Expansion board, transistor type, 2-point output
FX1N-4EX-BD Expansion board, 4-point input
FX1N-8AV-BD Handwritten input panel, suitable for FX1N
FX1N-232-BD RS-232 series one channel
FX1N-422-BD RS-422 series one channel
FX1N-485-BD RS-485 series one channel
FX1N-CNV-BD FX0N conversion unit interface
FX1N-EEPROM-8L PLC program conversion module

The FX1N series is a very powerful micro PLC, which can be expanded to up to 128 I/O points and can add special function modules or expansion boards. The communication and data link function options make the FX1N very good in important applications such as volume, communication and special function modules.

One PLC unit can output 2 points of 100KHz pulses at the same time. The PLC is equipped with 7 special positioning instructions, including zero return, position readout, absolute or relative drive and special pulse output control.

Other functions

Built-in 24V DC power supply

24V, 400mA DC power supply can be used for peripheral devices such as sensors or other components.

Clock function and hour meter function

A real-time clock is standard in all FX1NPLCs. Time setting and comparison instructions are easy to operate. The hour meter function provides valuable information for process tracking and machine maintenance.

Continuous scan function

Define the operating cycle for the continuous scan time required by the application.

Input filter adjustment function

Input filters can be used to smooth input signals (x000 to x017 in the basic unit).

Component annotation recording function

Component annotations can be recorded in program registers.

Online program editing

Change programs online without losing working time or stopping production operations.

RUN/STOP switch

The run/stop switch on the panel is easy to operate.

Remote maintenance

Remote programming software can monitor, upload or uninstall programs and data via modem communication

Password protection

Protect your program with an eight-digit password
